Complete Royal Enfield Bullet 500 Specifications

Royal Enfield Bullet 500 Specifications

Replicating the  Royal Enfield Bullet 500 specifications here because over time these go away from the official website. Last time around, I learnt this the hard way because I lost most of the AVL engined Royal Enfield Thunderbird 350 related information when Royal Enfield decided to phase it out, not only from the showrooms, but also from their website.

This page will keep getting updated as and when I find useful information to be used by owners of this model.

Why the interest and the special treatment to this motorcycle?

Just booked one today.

Royal Enfield Bullet 500 specifications

Royal Enfield Bullet 500 Specifications page image
Front 3/4

Engine

Type Single Cylinder, 4 stroke, Twinspark, Aircooled
Displacement 499cc
Bore x stroke 84mm x 90mm
Compression Ratio 8.5:1
Maximum Power 26.1 bhp @ 5100 rpm
Maximum Torque 40.9 Nm @ 3800 rpm
Ignition System TCI Unit, Multi curve
Clutch Wet, multi-plate
Gearbox 5 Speed Constant Mesh
Lubrication Wet sump
Engine Oil Oil 15 W 50 API, SL Grade JASO MA
Fuel Supply Carburettor with throttle position sensor
Air Cleaner Corrugated Paper Element
Engine Start Electric/Kick

Chassis & Suspension

Type Single downtube, using engine as stressed member
Front suspension Telescopic, 130mm travel
Rear suspension Twin gas charged shock absorbers, 80mm travel

Dimensions

Wheelbase 1370 mm
Ground Clearance 135 mm
Length 2140 mm
Width 810 mm (Without Mirror)
Height 1110 mm (Without Mirror)
Kerb Weight (with 90% Fuel ) 193 Kg
Fuel Capacity 13.5 Ltr

Brakes & Tyres

Tyres Fr. 90/90 – 19
Tyres Rr. 120/80 – 18
Brakes Front 280mm Disc, 2-Piston caliper
Brakes Rear 153mm Drum, Single Lead Internal Expanding

Electrical

Electrical System 12 volt – DC
Battery 12 volt, 14 Ah
Head Lamp 60/55 W, HALOG
Tail lamp 12V, 21W/5W

Spares for Royal Enfield Bullet 500

Added: 11th Jan 2014
A comprehensive list of spares for Royal Enfield Bullet 500. Useful if you plan to travel with this motorcycle. Though I created the page for the Classic series of motorcycles from RE, it holds good for this.

Bullet 500 Gallery
